Descrizione
| Type: | 5/8 λ ground plane |
| Radiation: | Omnidirectional |
| Polarization: | Linear vertical |
| Frequency range: | 26 … 28 MHz Tunable |
| Systems: | 10m-HAM |
| Gain: | 1.5 dBd, 3.65 dBi |
| Max Power: | 1000 Watts (CW) continuous 3000 Watts (CW) short time |
| Grounding protection: | DC-Ground |
| Connector: | UHF-female (SO-239) |
Mechanical Data:
| Materials: | Aluminium, Copper, Galvanized steel, Nylon |
| Height (approx): | 6700 mm / 21.98 ft |
| Weight (approx): | 6000 gr / 13.23 lb |
| Mounting type: | On-Mast |
